Machine Maintenance Procedures 3-45
3. Remove the yellow tape (C) securing the LVDS cable to the LCD panel connector
(Figure 3-46).
Figure 3-46. LVDS Cable
4. Starting from the top, remove the clear mylar tape (D) and disconnect the LVDS cable
from LCD panel connector (E) (Figure 3-47).
Figure 3-47. LVDS Cable
5. Remove the LVDS and camera cable from the LCD panel
.
C
E
D
