Replacing the Upper Case 0
1. Place the upper case on the base assembly and align it properly to the edge of the
system (Figure 3-73).
Figure 3-73. Replacing the Upper Case
2. Install and secure two (2) screws (C) to the upper case (Figure 3-74).
Figure 3-74. Touchpad FPC
3. Connect touchpad FPC (A) to mainboard connector (B) (Figure 3-74).
A
B
C
C
