3-72 Machine Maintenance Procedures
Replacing the Keyboard 0
1. Place the keyboard (C) face down on the palm rest (Figure 3-84).
Figure 3-84. Keyboard FPC
2. Connect keyboard FPC (A) to mainboard connector (B) (Figure 3-84).
3. Turn the keyboard over and align the keyboard tabs with the indentations in the
upper cover (Figure 3-85).
Figure 3-85. Keyboard Tabs
