Acer Aspire E1-421 - Replacing the DC-In Jack

3-54 Machine Maintenance Procedures
Replacing the DC-in Jack 0
1. Place DC-in Jack Module (A) on the base assembly (Figure 3-61).
2. Secure DC-in cable to the cable guide on the base assembly (Figure 3-61).
Figure 3-61. DC-in Jack Module
A
