3-8 Machine Maintenance Procedures
External Module Disassembly Process 0
External Modules Disassembly Flowchart 0
Figure 3-2. External Module Disassembly Flowchart
Table 3-2. Screw List
Step Size Quantity Acer Part No.
ODD Module Removal M2.5*6 1 86.A08V7.004
ODD Bracket Removal M2*3 2 86.SA107.001
Base Door Removal M2.5*6 4 86.A08V7.004
WLAN Module Removal M2*3 1 86.SA107.001
HDD Module Removal M3.0*3.5 Ni 4 86.WFB07.001
Battery
SD Dummy
Card
Base Door
DIMM
Module
HDD
Module
ODD
Module
WLAN
Module
Keyboard
