Acer Aspire E1-421 - Replacing the LCD Bracket

3-48 Machine Maintenance Procedures
Replacing the LCD Bracket 0
1. Place LCD bracket on the LCD panel (Figure 3-52).
Figure 3-52. LCD Bracket
2. Install and secure four (4) screws (A) to the LCD bracket (Figure 3-52).
ID Size Quantity Screw Type
A M2*3 4
A
A
A
A
