Acer Aspire E1-421 - ODD (Optical Disk Drive) Module Removal

Machine Maintenance Procedures 3-11
ODD (Optical Disk Drive) Module Removal 0
Prerequisite:
Battery Pack Removal
1. Remove one (1) screw (A) securing the ODD module in place (Figure 3-6).
2. Grasp the ODD bezel (B) to remove ODD module from ODD bay (Figure 3-6).
Figure 3-6. ODD Module
3. Remove two (2) screws (C) from ODD module (Figure 3-7).
4. Remove ODD bracket (D) from ODD module (Figure 3-7).
5. Remove ODD bezel (B) from ODD module (Figure 3-7).
Figure 3-7. ODD Bracket
B
A
D
B
C
C
