Acer Aspire E1-421 - LCD 14.0 (Continued)

Hardware Specifications and Configurations 1-33
LCD 14.0” (Continued)
Item Specification
Vendor & Model name Chimei
N140BGE
Chimei
BT140GW01
Screen Diagonal (mm) 354.95
Active Area (mm) 309.40 x 173.95
Display resolution (pixels) 1366 horiz. x 768 vert.
Pixel Pitch (mm) 0.2265 x 0.2265
Typical White Luminance
(cd/m
2
) also called
Brightness
200 typ. (5 points average)
170 min. (5 points average)
220 typ. (5 points average)
190 min. (5 points average)
Contrast Ratio 500 min. / 600 typ. 500 min. / 600 typ.
Response Time (Optical
Rise Time/Fall Time) msec
6 typ. / 12 max 8 typ. / 15 max.
Typical Power
Consumption (watt)
Total: 3.7 W max.
Logic: 0.7W
B/L: 3.0W
Total: 4 W max.
Logic: 0.9W
B/L: 3.1W
Weight (without inverter) 350 max.
Physical Size (mm) 324 (H) x 192.5 (V) x 5.2 (D)
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right)
CR = 10 (Left)
Vertical (Upper)
CR = 10 (Lower)
40 min.
40 min.
10 min.
30 min.
40 min.
40 min.
15 min.
30 min.
