Acer Aspire E1-421 - Replacing the DIMM (Dual In-Line Memory Module) Module3-69

Machine Maintenance Procedures 3-69
Replacing the DIMM (Dual In-line Memory Module) Module 0
1. Insert DIMM into mainboard connector (B) (Figure 3-79).
2. Push down on DIMM until module clips (A) lock in position (Figure 3-79).
Figure 3-79. DIMM Modules
3. Repeat steps 1 and 2 for remaining modules.
A
A
B
