1-14 Hardware Specifications and Configurations
Figure 1-4. Left View
Table 1-4. Left View
# Icon Item Description
1 DC-in jack Connects to an AC adapter.
2 Ethernet (RJ-45) port
Connects to an Ethernet 10/100/1000 based
network.
3
External display
(VGA) port
Connects to a display device (e.g., external
monitor, LCD projector).
4HDMI port
Supports high-definition digital video
connections.
5
USB 2.0/3.0 combo
port
Connects to USB 2.0 or USB 3.0 devices (e.g.,
USB mouse, USB camera)
6
Microphone jack Accepts inputs from external microphones.
Headphone/
speaker jack
Connects to audio line-out devices (e.g.,
speakers, headphones).
