1-16 Hardware Specifications and Configurations
Figure 1-6. Base View
Table 1-6. Base View
# Icon Item Description
1 Battery bay Houses the computer's battery pack.
2 Battery lock Locks the battery in position.
3 Speakers Emits audio from your computer.
3
Hard disk bay
Houses the computer’s hard disk (secured with
screws).
Memory compartment Houses the computer’s main memory
4 Speakers Emits audio from your computer.
5
Ventilation slot and
cooling fan
Enable the computer to stay cool, even after
prolonged use.
Note: Do not cover or obstruct the opening of
the fan.
