Acer Aspire E1-531 - USB Module Installation

Service and Maintenance 3-67
USB Module Installation
1. Align the USB connectors to the connector slots on the lower case.
Figure 3:100. Installing the USB Module
2. Attach the screw to secure the USB module to the lower case.
Figure 3:101. Securing the USB Module Screw
