Acer Aspire E1-531 - Maintenance Flowchart

3-4 Service and Maintenance
Maintenance Flowchart
The flowchart in Figure3-1 provides a graphic representation of the module removal and installation
sequences. It provides information on what components need to be removed and installed during
servicing
Figure 3:1. Maintenance Flow
Battery
Dummy Card Keyboard
DIMM Module WLAN Module
ODD Module
LCD Module
Speaker
Module
Mainboard
CPU
Thermal
Module
Fan
USB ModuleRTC Battery
Upper Cover
HDD Module
HDD Carrier
Power Board Touchpad FFC
Base Door
