Hardware Specifications and Configurations 1-8
Left View
Figure 1:3. Left View
# Icon Item Description
1 DC-In Jack Connects to an AC adapter.
2
Ethernet (RJ-45)
Port
Connects to an Ethernet 10/100/1000-based network.
3Air Vents
Use for air flow.
CAUTION:
Do not cover the air vents.
4 VGA Port Connects to a VGA cable for external video output.
5 HDMI Port Supports high-definition digital video connections.
6 USB 2.0 Port Connects to USB 2.0 devices.
7 Microphone Jack Connects to a microphone.
8 Headset Jack Connects to a headset.
