Jumper and Connector Locations 5-7
Power Board View
Figure 5:4. Power Board
Table 5:4. Power Board Jumper and Connectors
Item Description
LED1 Power LED (VA50)
LED2 Power LED (VG50)
LED3 Power LED (EA50, EG50)
SW1 Power Button Switch (VA50, VG50)
SW2 Power Button Switch (EA50, EG50)
JPWR1 Power FFC Connector
