3-72 Service and Maintenance
3. Attach the screw to secure the power board to the upper case.
Figure 3:108. Securing the Power Board Screw
4. Install the upper case (see Upper Case Installation on page 3-38).
Table 3:14. Power Board Screw
Screw Name Screw Type Quantity
M 2.0 x 3.0 1
