1-25 Hardware Specifications and Configurations
LED 15.6”
Item Specification
Vendor/Model name
• AUO/B156XW02 V6 (HW:0A)
• AUO/B156XW02 V2 (HW:4A)
• Samsung/LTN156AT02-A11
• LG/LP156WH2-TLEA
• CMO/N156B6-L0B
• CPT/ CLAA156WB11A
Screen Diagonal (mm) 394.91 mm
Active Area (mm) 344.23 mm x 193.54 mm
Display resolution (pixels) 1366 x 3(RGB) x 768
Pixel Pitch (mm) 0.252mm × 0.252 mm
Typical White Luminance (cd/m
2
)
also called Brightness
200 cd/m
2
Contrast Ratio 400 min / 500 type
Response Time (Optical Rise
Time/Fall Time) msec
8 ms / 16 ms
Typical Power Consumption
(watt)
5.15 W
Weight (without inverter) 460 max
Physical Size (mm) 360 mm x 210mm x 5.5 max
Electrical Interface 1 channel LVDS / e-DP (option)
Viewing Angle (degree)
Horizontal (Right) CR = 10 (Left)
Vertical (Upper) CR = 10 (Lower)
40 (Right) / 40 (Left) / 10 (Upper) / 30 (Lower) min.
