Hardware Specifications and Configurations 1-30
AC Adapter
System Power Management
Card Reader
Item Specification
Input rating
65 W & 90 W
Maximum input AC current
65 W: 1.5A at 100V
90 W: 1.7A at 100V
Inrush current
12t at 264V, no damage to adapter
Efficiency
Refer to EPA 2.0
Item Specification
Mech. Off (G3) Al devices in the system are turned off completely.
Soft Off (G2/S5)
OS initiated shutdown. All devices in the system are turned off
completely.
Working (G0/S0)
Individual devices such as the CPU and hard disc may be
power managed in this state.
Suspend to RAM (S3)
• CPU set power down
• VGA Suspend
• PCMCIA Suspend
• Audio Power Down
• Hard Disk Power Down
• CD-ROM Power Down
• Super I/O Low Power mode
Save to Disk (S4)
Also called Hibernation Mode. System saves all system states
and data onto the disc prior to power off the whole system.
Item Specification
Chipset Broadcom BCM57785X
Package QFN68pin
Maximum supported size
• SDHC: 32G (8G tested)
• MMC: 16G (4G tested)
• miniSD: 16G
• MS/MS-PRO: 16G (8G tested)
• XD Picture: 2G
Features
5 in 1 card reader, supporting:
• Secure Digital™ (SD) Card, MultiMediaCard™ (MMC)
• Storage cards with adapter: miniSD™
• Memory Stick, Memory Stick PRO
• xD Picture
