Color-coded Pop-up Messages and Problem Conditions
90 | ACIST RXi System User’s Guide 901700-001,01 2019-09 English
Troubleshooting and Support
Color Message Corrective Action or Explanation
Blue The case was successfully exported. The FFR data was successfully exported. You may
remove the USB memory device.
Blue The FFR recording has been discarded.
Please check the aortic pressure cable.
Press OK to conrm and close the message.
This is a notication that the FFR data has been
interrupted because there is a problem with the
aortic cable. Check the aortic cable connection.
Blue The FFR recording has been discarded.
The system has detected a problem with the
pressure sensor.
Press OK to conrm and close the message.
This is a notication that the FFR data has been
interrupted because there is a problem with
the pressure sensor (located within the Navvus
MicroCatheter). Inspect the microcatheter,
unplug and plug in if needed, or replace
the microcatheter. Note: If you unplug the
microcatheter it ends the case.
Blue The FFR recording has been discarded.
The aortic pressure is out of range.
Press OK to conrm and close the message.
This is a notication that the FFR data has been
interrupted because the aortic pressure was
out of range. Determine why aortic pressure is
reading high or low.
Blue The software installation completed
successfully.
Please remove the USB memory stick and
restart the system.
The software download is complete. Remove the
USB memory device and restart the system.
