ADC AD-320 User Manual

112144-46 www.adclaundry.com 9
MAXIMUM CAPACITY (DRY WEIGHT) PER POCKET 30 lb
13.60 kg
TUMBLER DIAMETER 27-1/4”
69.2 cm
TUMBLER DEPTH 30”
76.2 cm
TUMBLER VOLUME PER POCKET 10.1 cu ft
286.0 L
TUMBLER/DRIVE MOTOR PER POCKET 1/3 hp
0.25 kW
BLOWER/FAN MOTOR PER POCKET N/A
DOOR OPENING (DIAMETER) 21-1/2”
54.6 cm
DOOR SILL HEIGHT TOP POCKET / BOTTOM POCKET 52-3/8” / 14-1/4”
133.033 cm / 36.195 cm
WATER CONNECTION 3/4”-11.5 NH (North America)
3/4” B.S.P.T. (Outside North America)
DRYERS PER 20’/40’ CONTAINER 14 / 28
DRYERS PER 48’/53’ TRUCK 34 / 36
VOLTAGE AVAILABLE 100-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 793 lb
359.7 kg
APPROXIMATE SHIPPING WEIGHT 860 lb
390.1 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
HEAT INPUT PER POCKET 68,000 Btu/hr
17,135 kcal/hr
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION N/A
COMPRESSED AIR VOLUME N/A
INLET PIPE CONNECTION PER POCKET 1/2” F.N.P.T.
1/2” B.S.P.T. (CE and Australia Only)
VOLTAGE AVAILABLE 208-416V 1,3ø 2,3,4w 50/60 Hz
APPROXIMATE NET WEIGHT 793 lb
359.7 kg
APPROXIMATE SHIPPING WEIGHT 860 lb
390.1 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION N/A
COMPRESSED AIR VOLUME N/A
OVEN SIZE PER POCKET
kW Btu/hr
kcal/hr
15 51,228
12,910
VOLTAGE AVAILABLE 100-240V 1ø 2w 50/60 Hz
APPROXIMATE NET WEIGHT 837 lb
379.7 kg
APPROXIMATE SHIPPING WEIGHT 884 lb
401.0 kg
AIRFLOW PER POCKET
60 Hz
400 cfm
11.33 cmm
50 Hz
333 cfm
9.44 cmm
STEAM CONSUMPTION PER POCKET 101 lb/hr
45.8 kg/hr
OPERATING STEAM PRESSURE 125 psi max
8.6 bar
EXHAUST CONNECTION (DIAMETER) PER POCKET 6”
15.24 cm
COMPRESSED AIR CONNECTION PER POCKET 1/8” F.N.P.T.
COMPRESSED AIR VOLUME 0.5 cfh
0.014 cmh
BOILER HORSEPOWER (NORMAL LOAD) PER POCKET 2.9 Bhp
SUPPLY CONNECTION PER POCKET 1” F.N.P.T.
RETURN CONNECTION PER POCKET 3/4” F.N.P.T.
B. SPECIFICATIONS (AD-330)
GASELECTRICSTEAM*
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
Shaded areas are stated in metric equivalents 5/11/12
* Dryer must be provided with clean, dry and regulated 80 psi +/- 10 psi (5.51 bar +/- 0.69 bar) air supply.

ADC AD-320 Specifications

General

Brand	ADC
Model	AD-320
Category	Controller
Language	English
