36 American Dryer Corporation 450239-4
S.A.F.E. Temperature Probe Assembly
Illus. No. Part No. Qty. Description
18523231Temperature Sensor Assembly (1 required per pocket)
(includes illus. nos. 1 through 5)
215400721/4” Push-On Fastener
33903901Sensor Activated Fire Extinguishing System Sensor Mounting Plate
41504112#8-18 x 3/8” Phillips Pan Head TEK Screw
51226432#20-16 Pin
122647 1 2-Pin Cap Connector ONLY (no pins)
