6American Dryer Corporation450239-4
AD-320 Lint Drawer (Basket) Assembly
Illus. No. Part No. Qty. Description
18834551AD-320 White Lint Drawer (basket) Assembly Complete
(includes illus. nos. 1 and 2)
883457 1 AD-320 Ivory Lint Drawer (basket) Assembly Complete
(includes illus. nos. 1 and 2)
883456 1 AD-320 Coral Blue Lint Drawer (basket) Assembly Complete
(includes illus. nos. 1 and 2)
883458 1 AD-320 Black Lint Drawer (basket) Assembly Complete
For Stainless Steel Models ONLY
21176041Neoprene Sponge Tape (sold by the foot)
3––––––1Temperature Sensor Bracket
(refer to Temperature Sensor Probe Assembly on page 21)
4––––––1Lint Drawer (basket) Switch
(refer to AD-330 / AD-320 Lint Drawer [Basket] Switch Assembly on page 23)
IMPORTANT: For models with optional lock refer to AD-320 Locking Lint Drawer (Basket) Assembly on page 8.
