ADC AD-320 - Kw Electric Oven Component Chart

38 American Dryer Corporation 450239-4
15 kW Electric Oven Component Chart
* When ordering electric oven assembly complete specify 3-wire or 4-wire when applicable.
Voltage Phase
Oven
Assembly *
Part No.
Element
Oven Wire
Assembly with
Crimp Terminal
Terminal Lug
Bus Bar
Part No.
112011
Oven
Relay
Qty. kW Part No. Size Part No. Qty. Part No. Part No.
208 1ø 824957 6 2.5 120036 #4 830421 1 121012 6’ 131376
240 1ø 843243 6 2.5 120040 #4 830421 1 121012 6’ 131369
208 3ø 883802 6 2.5 120036 #8 830422 1 121012 2’ 131357
240 3ø 883803 6 2.5 120040 #8 830422 1 121010 2’ 131357
380 3ø 883804 6 2.5 120038 #8 830423 1 121010 2’ 131352
416 3ø 883805 6 2.5 120036 #8 830423 1 121010 2’ 131352
For models prior to September 24, 2013
For models as of September 24, 2013
Voltage Phase
Oven
Assembly *
Part No.
Element
Oven Wire
Assembly with
Crimp Terminal
Terminal Lug
Bus Bar
Part No.
112011
Oven
Relay
Qty. kW Part No. Size Part No. Qty. Part No. Part No.
208 1ø 824957 6 2.5 120036 #4 830421 1 121012 6’ 131332
240 1ø 843243 6 2.5 120040 #4 830421 1 121012 6’ 131332
208 3ø 883802 6 2.5 120036 #8 830422 1 121012 2’ 131332
240 3ø 883803 6 2.5 120040 #8 830422 1 121010 2’ 131332
380 3ø 883804 6 2.5 120038 #8 830423 1 121010 2’ 131332
416 3ø 883805 6 2.5 120036 #8 830423 1 121010 2’ 131332
* When ordering electric oven assembly complete specify 3-wire or 4-wire when applicable.
