ADC AD-320 - Optional Exhaust Duct Kit; Optional Gas Piping Kit

112144-46 www.adclaundry.com 55
Optional Exhaust Duct Kit (ADG-330, ADG-320)
ADC Part No. 882035
Optional Gas Piping Kit (ADG-330, ADG-320)
ADC Part No. 880128
ITEM # QTY P/N DESCRIPTION
1 1 143600 10” X 6” X 6”, Y DUCT
2 1 143519 FLEX DUCT 6” x 4’ LONG
3 1 143509 FLEX DUCT 6” x 8’ LONG
4 2 143536 45º ELBOW 6”
5 12 150300 #10 x 1/2” SELF DRILLING SCREW
NOT ILLUSTRATED 12’ 117505 ALUMINUM DUCT TAPE
