SECTION III
INSTALLATION PROCEDURES
Installation should be performed by competent technicians in accordance with local and state codes. In the absence
of these codes, the installation must conform to applicable American National Standards: ANSI Z223.1-LATEST
EDITION (National Fuel Gas Code) or ANSI/NFPA NO. 70-LATEST EDITION (National Electrical Code) or in
Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural Gas)
or CAN/CGA-B149.2-M91 (Liquid Propane [L.P.] Gas) or LATEST EDITION (for General Installation and Gas
Plumbing) or Canadian Electrical Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION (for Electrical
Connections).
A. UNPACKING/SETTING UP
Remove protective shipping material (i.e., plastic wrap and/or optional shipping box) from dryer.
NOTE: The access keys for the service doors are included in the information packet shipped in the
basket (tumbler). These keys should be removed and put in a safe place yet made accessible
because some will be needed throughout various phases in the installation of the dryer.
Dryers are shipped with a coin box and coin box faceplate ONLY. The coin box lock is not included and must
be purchased elsewhere or the lock can be ordered as a parts order from the ADC factory.
The dryer can be moved to its final location while still attached to the skid or with the skid removed. To unskid the
dryer, locate and remove the four (4) bolts securing the base of the dryer to the wooden skid. Two (2) are at the rear
of the base, and two (2) are located in the front. Once the bolts are removed, slide the dryer off the skid.
With the skid removed, to make it easier to slide the dryer into its final position, slightly lower ALL four (4) leveling
legs, so that the dryer will slide on the legs instead of the base frame. The dryer is equipped with four (4) leveling
legs, one (1) at each corner of the dryer base. The hex head adjustment bolts for the two (2) front leveling legs are
located directly behind the lower access door, and the rear two (2) adjustments are directly behind the lower rear
back (guard) panel.
For more effective automatic door closure and better tumbling action (and improved efficiency), the dryer should be
tilted slightly to the rear.
B. LOCATION OF THE DRYER
Before installing the dryer, be sure the location conforms to local codes and ordinances. In the absence of such
codes or ordinances the location must conform with the National Fuel Gas Code ANSI.Z223.1 LATEST EDITION,
or in Canada, the installation must conform to applicable Canadian Standards: CAN/CGA-B149.1-M91 (Natural
Gas) or CAN/CGA-B149.2-M91 (L.P. Gas) or LATEST EDITION (for General Installation and Gas Plumbing).
The dryer must be installed on a sound level floor capable of supporting its weight. Carpeting must be removed
from the floor area that the dryer is to rest on.
IMPORTANT: “The dryer must be installed on noncombustible floors only.”
