24 American Dryer Corp. 112144-46
Check your national and local code for breaker and wire size 7/9/14
NOTE: Contact factory for electrical information not listed.
NOTE: ADC reserves the right to make changes in specifications at any time without notice or
obligation.
ADE-320 / ADE-330
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT:
NOTES: A.
B.
C.
208 VAC AND 230/240 VAC ARE NOT THE SAME. When ordering, specify exact
voltage.
When fuses are used they must be dual element, time delay, current limiting, class
RK1 or RK5 ONLY. Calculate/determine correct fuse value, by applying either
local and/or National Electrical Codes to listed appliance amp draw data.
Circuit breakers are thermal-magnetic (industrial) type ONLY. For others,
calculate/verify correct breaker size according to appliance amp draw rating and
type of breaker used.
Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
kW
APPROX.
AMP DRAW
CIRCUIT
BREAKER
60 Hz 50 Hz
208 1ø 2 15 77
—
100
220 1ø 2 13 65
—
90
240 1ø 2 15 67 67 90
208 3ø 3 15 47
—
60
220 3ø 3 13 40 38 50
240 3ø 3 15 42 40 60
480 3ø 3 15 41
—
60
230 3ø 3 14
—
39 50
380 3ø 4 13
—
24 40
416 3ø 4 15
—
25 40
