ADC AD-320 User Manual

450239-4 www.adclaundry.com 13
DMC Control Box Assembly
Illus. No. Part No. Qty. Description
18523261Control Box Assembly Complete – 120V
(includes illus. nos. 1 through 26)
852337 1 Control Box Assembly Complete – 208-240V
(includes illus. nos. 1 through 26)
850911 1 Electric Box ONLY
21501082#8-32 x 1/2” Phillips Pan Head Machine Screw
38523331Transformer – 24 VAC Assembly (for 120V 50/60 Hz models Only)
852335 1 Transformer – 24 VAC (for 208-240V 50/60 Hz models Only)
41510012#8-32 Pal Nut
51510003#6-32 Pal Nut
61360081Fuse Block
71500022#6-32 x 1” Round Head Machine Screw
813604913/4-Amp (Slo-Blo) Fuse (for 120V 50/60 Hz models Only)
136057 1 1/2-Amp (Slo-Blo) Fuse (for 208-240V 50/60 Hz models Only)
912149410Push Mount Wire Tie
10 120715 1 30-Position Terminal Block
11 121010 2 L-70 Terminal Lug
12 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
13 132475 2 2-Pole Contactor
14 824828 2 R.C. Network with Connectors
15 150001 1 #6-32 x 1/2” Phillips Round Head Machine Screw
16 315023 1 E-Box Back Phase 7 Coin
17 153010 1 #6 Interior and Exterior Star Washer
18 120910 2 #10-32 Green Ground Screw
19 122689 1 16-Pin Connector
20 182363 16 Male Crimp Pin (for illus. no. 19)
21 122687 1 20-Pin Connector
22 182363 20 Male Crimp Pin (for illus. no. 21)
23 122626 1 15-Pin Connector
24 122705 15 Female Crimp Socket (for illus. no. 23)
25 122685 1 14-Pin Connector
26 182363 14 Male Crimp Pin (for illus. no. 25)
27 122667 1 16-Pin Connector
28 122669 16 Female Crimp Socket (for illus. no. 27)
29 122668 1 20-Pin Connector
30 122669 20 Female Crimp Socket (for illus. no. 29)
31 122625 1 15-Pin Connector
32 122704 15 Male Crimp Pin (for illus. no. 31)
33 122686 1 14-Pin Connector
34 122669 14 Female Crimp Socket (for illus. no. 33)
122672 1 Pin / Socket Extraction Tool … Not Illustrated
