450239-4 www.adclaundry.com 27
AD-330 / AD-320 Gas Train Assembly
Illus. No. Part No. Qty. Description
11411301Up-Shot Gas Burner
21289171Spark Ignitor
31289181Flame Sensor
43180091Burner Tube Bracket
5140823* 1AD-320 #26 Burner Orifice (natural gas) ONLY
140809* 1AD-320 #43 Burner Orifice (liquid propane gas) ONLY
140856* 1AD-330 #23 Burner Orifice (natural gas) ONLY
140810* 1AD-330 #42 Burner Orifice (liquid propane gas) ONLY
61412451AD-320 14-7/16” Single-Port Manifold
141225 1 AD-330 19-7/16” Single-Port Manifold
73186001Manifold Bracket
8883439** 1AD-320 Direct Spark Ignition Natural Gas Train Assembly Complete
(includes illus. nos. 1 through 4, 6 through 14, 16 through 22, and 24 through 26)
883438** 1AD-320 Direct Spark Ignition Liquid Propane Gas Train Assembly Complete
(includes illus. nos. 1 through 4, 6 through 14, 16 through 22, and 24 through 26)
319525 1 AD-320 Gas Train Slide ONLY
883436** 1AD-330 Direct Spark Ignition Natural Gas Train Assembly Complete
(includes illus. nos. 1 through 4, 6 through 14, 16 through 22, and 24 through 26)
883437** 1AD-330 Direct Spark Ignition Liquid Propane Gas Train Assembly Complete
(includes illus. nos. 1 through 4, 6 through 14, 16 through 22, and 24 through 26)
319522 1 AD-330 Gas Train Slide ONLY
93187111Notched Pipe Bracket
10 884126 1 Fenwal Direct Spark Ignition Conversion Kit (one pocket)
883848 1 Fenwal Direct Spark Ignition Conversion Kit (two pockets)
11 152013 2 #6-32 Hex Nut
12 121300 2 Open / Closed Bushing
13 150301 4 #8-18 x 7/16” Phillips Pan Head TEK Screw
14 121499 6 3/16” Push Mount Wire Tie
15 142934 1 1/2” Coupling with Mounting Tabs
16 128927 1 1/2” 24 VAC Direct Spark Ignition Redundant Gas Valve (natural gas) ONLY
880960 1 Direct Spark Ignition Gas Valve (liquid propane gas) ONLY
17 142506 1 1/2” x 1/2” Street Elbow
18 318712 1 Gas Valve Pipe Bracket
19 882157 1 1/4” Aluminum Tubing (12” length)
20 143203 1 Aluminum Tubing Adapter
21 143259 1 Aluminum Tubing Compression Fitting
22 151001 8 #8-32 Pal Nut
23 142809 1 AD-320 1/2” x 29-1/8” Pipe
142805 1 AD-330 1/2” x 34-1/2” Pipe
24 153528 8 #8-32 x 1/2” Self-Clinching Stud
25 815974 1 Direct Spark Ignition Module Mounting Bracket (Johnson)
26 141317 1 1/2” Bronze Union Elbow
27 122701 2 Socket Terminal ONLY
28 122604 1 4-Pin Connector (male)
29 122700 2 Pin Terminal ONLY
*Consult factory for elevations over 2,000 feet.
** Orifice is not included and must be ordered separately.
