User’s Manual
V1.0
48
INPUTS/OUTPUTS
Alarm Input 4 TTL, programmable as NC or NO, 4.3V threshold
Alarm Output
1 relay output, terminal blocks, programmable as NC or NO, 2A@125VAC,
1A@30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45)
CONNECTORS
Video Input Composite: 4 BNC
Video Loop Composite: 4 BNC (Auto Terminating)
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
Alarm Input/Output Terminal blocks
Ethernet Port RJ-45
RS485 Serial Port Two-connector terminal block
USB Port 1 (USB 2.0) on the front panel
Mouse Port 1 (USB) on the rear panel
IR Port 1 Remote Control
STORAGE
Primary Storage SATA hard disk drive
Secondary Storage USB flash drive
GENERAL
Dimensions (W x H x D)
13.4" x 1.8" x 12.2" (340mm x 46.5mm x 310mm)
Unit Weight 6.6 lbs. (3.0kg)
Shipping Weight 9.9 lbs. (4.5kg)
Shipping Dimensions
(W x H x D)
17.3" x 5.6" x 16.1" (440mm x 143mm x 410mm)
Operating Temperature 41°F to 104°F (5°C to 40°C)
Operating Humidity 0% to 90%
Power 100–240 V~, 50/60Hz, 0.8–0.4 A
Power Consumption Max. 25W
Approvals FCC, UL*, CE
* CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions. This equipment
is indoor use and all the communication wiring are limited to inside of the building.
Specifications are subject to change without notice.
