4-Channel Digital Video Recorder
15
NOTE: The higher Quality settings require higher Transfer Speed settings. The transfer speed you set is the
maximum speed. Depending on the network environment, this speed may not be achieved.
You can limit the network bandwidth settings so that system does not consume too much network bandwidth. Highlight the
box beside Network Bandwidth Limit and press the Up and Down arrow buttons to set the desired maximum bandwidth
from 10Kbps to 100Mbps.
NOTE: When limiting the network bandwidth, the remote watch image on the PC running RAS or WebGuard
might not be displayed properly.
Highlight Enable SSL for Transferring Data and press the button to toggle between On and Off. When it is On,
the security of data except video transmitted for remote monitoring or remote recording can be enhanced by using the
SSL (Secure Sockets Layer) authentication. When using the SSL function, the DVR cannot be connected with a remote
program or a network keyboard which does not support the SSL function.
CAUTION: The remote connection will be disconnected temporarily after changing the SSL settings.
NOTE: This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit
(http://www.openssl.org/).
Highlight the LAN tab, and the LAN setup screen displays.
NOTE: You will need to get the appropriate IP Address, Gateway and Subnet Mask from your network administrator.
Highlight the box beside DNS Server. Press the Up and Down arrow buttons to set the IP address of the DNS server.
Highlight the Port Number Setup… box and press the button. The Port Number Setup screen appears.
Figure 16 ─ Network setup screen.
Highlight the first box beside Remote Watch – Transfer
Speed. Press the Up and Down arrow buttons to set the
Transfer Speed from 50Kbps to 100Mbps.
Highlight the second box beside Remote Watch – Transfer
Speed. You can select the unit of measure for the transfer
speed between: bps and ips. Press the
button to set the
transfer speed.
NOTE: The local recording speed might be affected by
various network bandwidth (Transfer Speed) conditions.
Highlight the box beside Remote Watch – Quality and press
the
button. You can select the Quality from: Very High,
High, Standard and Basic. Press the
button to set the
Quality.
Figure 17 ─ LAN (Manual) setup screen.
Highlight the box beside Type and press the button. You
can select the type of network configuration from: Manual,
DHCP and ADSL (with PPPoE). Select the desired type
and press the
button.
Selecting Manual from the Type allows you to set up LAN
parameters manually.
Change the numbers by highlighting them and using the Up
and Down arrow buttons to increase or decrease the number.
The factory default LAN settings are:
IP Address: 192.168.1.229
Gateway: 192.168.1.1
Subnet Mask: 255.255.255.0
