Table 1.7: ADAM-5017H Input Signal Ranges
Input
Range
With
Over-
ranging
Offset
Error @
25°C
Offset
Error @
-10 to
+70°C
Gain
Error
@ 25°C
Gain Error
@ -10 to
+70°C
Offset Drift Gain
Drift
Display
Resolution
Voltage
Inputs
0 ~ 10 V 0 ~ 11 V ±1 LSB ±2 LSB ±1 LSB ±2 LSB 17 µV/°C 50 ppm/
°C
2.7 mV
0 ~ 5 V 0 ~ 5.5 V ±1 LSB ±2 LSB ±1.5
LSB
±2 LSB 16 µV/°C 50 ppm/
°C
1.3 mV
0 ~ 2.5 V 0 ~ 2.75
V
±1 LSB ±2 LSB ±1.5
LSB
±2 LSB 20 µV/°C 55 ppm/
°C
0.67 mV
0 ~ 1 V 0 ~
1.375 V
±1 LSB ±2.5
LSB
±2 LSB ±2.5 LSB 20 µV/°C 60 ppm/
°C
0.34 mV
0 ~ 500
mV
0 ~
687.5
mV
- ±5 LSB ±3 LSB ±3.5 LSB 20 µV/°C 67 ppm/
°C
0.16 mV
± 10 V ±11 V ±1 LSB ±2 LSB ±1 LSB ±2 LSB 17 µV/°C 50 ppm/
°C
2.7 mV
± 5 V ±0 ~ 5.5
V
±1 LSB ±2 LSB ±1.5
LSB
±2 LSB 17 µV/°C 50 ppm/
°C
1.3 mV
± 2.5 V ±0 ~
2.75 V
±1 LSB ±2 LSB ±1.5
LSB
±2 LSB 20 µV/°C 55 ppm/
°C
0.67 mV
± 1 V ±0 ~
1.375 V
±1 LSB ±2.5
LSB
±2 LSB ±2.5 LSB 20 µV/°C 60 ppm/
°C
0.34 mV
± 500 mV ±0 ~
687.5
mV
- ±5 LSB ±3 LSB ±3.5 LSB 20 µV/°C 67 ppm/
°C
0.16 mV
Current
Inputs
0 ~ 20 mA 22 mA ±1 LSB ±1 LSB ±1.5
LSB
±2 LSB nA/°C ppm/°C 5.3 µ
4 ~ 20 mA 22 mA ±1 LSB ±1 LSB ±1.5
LSB
±2 LSB nA/°C ppm/°C 5.3 µ
