Advantech ADAM-5050 User Manual

27 ADAM-5000 Series User Manual
Chapter 3 Analog I
/
O Module Calibration
Table 3.1: Calibration Voltage of ADAM-5017/5018
Module Input Range
Code (Hex)
Input Range Span Calibration
Voltage
5018 00h ±15 mV +15 mV
01h ±50 mV +50 mV
02h ±100 mV +100 mV
03h ±500 mV +500 mV
04h ±1 mV +1 V
05h ±2.5 V +2.5 V
06h ±20 mV +20 mA (1)
0Eh J thermocouple 0 to 1370°C +50 mV
0Fh K thermocouple 0 to 1370°C +50 mV
10h T thermocouple -100 to 400°C +22 mV
11h E thermocouple 0 to 1000°C +80 mV
12h R thermocouple 500 to 1750°C +22 mV
13h S thermocouple 500 to 1800°C +22 mV
14h B thermocouple 500 to 1800°C +152 mV
5017 07h Not used
08h ºC ±10 V +10 V
09h ±5 V +5 V
0Ah ±1 V +1 V
0Bh ±500 mV +500 mV
0Ch ±150 mV +150 mV
0Dh ±20 mA +20 mV (1)
Table 3.2: Calibration Voltage (ADAM-5017H)
Module Input Range Code
(Hex)
Input Range Span Calibration Voltage
5017H 00h ±10 V +10 V
01h 0 ~ 10 V +10 V
02h ±5 V +5 V
03h 0 ~ 5 V +5 V
04h ±2.5 V +2.5 V
05h 0 ~ 2.5 V +2.5 V
06h ±1 V +1 V
07h 0 ~ 1 V +1 V
08h ±500 mV +500 mV
09h 0 ~ 500 mV +500 mV
0ah 4 ~ 20 mA *(1)
0bh 0 ~ 20 mA *(1)
Note! You can substitute 2.5 V for 20 mA if you remove the current conversion
resistor for that channel. However, the calibration accuracy will be lim-
ited to 0.1% due to the resistor's tolerance.
