ADAM-5000 Series User Manual 80
Maximum Bit Rate vs. Bus Length
For a Controller Area Network, the maximum possible bus length depends on the bit
rate. The bit rate can always be slower than the maximum possible speed for a given
bus length. Conversely, the bus length can be shorter than the maximum possible
bus length for a given transmission speed.
Table 7.12: Maximum Bit rate vs. Bus Length
Bit Rate Bus Length
1M bps 25m
800k bps 50m
500k bps 100m
250k bps 250m
125k bps 500m
50k bps 1000m
20k bps 2500m
10k bps 5000m
