Table 1.8: Technical Specifications of ADAM-5017UH
Analog Input Channels Eight differential
Resolution 12 bits
Input Type mV, V, mA
Input Range +0~10V , ± 10 V , +4~20mA and ± 20 mA
Isolation Voltage 3000 VDC
Sampling Rate 200k samples/sec (single channel)
50k samples/sec (8 channel)
Analog Input Signal Limit 15 V max.
Max. allowable voltage dif-
ference between two con-
nectors in a module
15 V max.
Input Impedance
2M
 (voltage input)
120
 (current input)
Bandwidth 200kHz
Accuracy ± 0.1% or better
Low or high pass filter Configured by User
CMR @ 50/60 Hz 92 dB min.
Power Requirements + 10 to + 30 VDC (non-regulated)
Power Consumption 1.75 W (typical ); 2.2W (max)
Signal Input Bandwidth 200kHz for both voltage and current inputs
Table 1.9: ADAM-5017UH Input Sgnal Ranges
Input Range Offset
Error @
25°C
Offset Error @
-10 to +70°C
Gain Error
@ 25°C
Gain Error @
-10 to +70°C
Display
Resolution
Voltage
Inputs
0 ~ 10 V ±1 LSB ±2 LSB ±1 LSB ±2 LSB 2.7 mV
± 10 V ±1 LSB ±2 LSB ±1 LSB ±2 LSB 2.7 mV
Current
Inputs
0 ~ 20 mA ±1 LSB ±1 LSB ±1.5 LSB ±2 LSB 5.3 µ
4 ~ 20 mA ±1 LSB ±1 LSB ±1.5 LSB ±2 LSB 5.3 µ
