A Technical Specifications
IST Series UPS (10kVA-200kVA)
User Manual
90
Model
Index
10kVA
20kVA
30kVA
40kVA
50kVA
60kVA
80kVA
100kVA
140kVA
160kVA 200kVA
Overload capacity
Inverter overload capacity:
When the load less than 105％ rated load, it runs normally.
When the load in the range of 105%~115％ rated load, it will turns to
bypass 60min later.
When the load in the range of 116%~130％ rated load, it will turns to
bypass 10min later.
When the load in the range of 131%~150％ rated load, it will turns to
bypass 1min later.
When the load in the range of 151%~250％ rated load, it will turns to
bypass 200ms later.
When the load greater than 251％ rated load, it will turns to bypass
10ms later.
Bypass overload capacity:
When the load less than 130％ rated load, it runs normally.
When the load in the range of 131%~150％ rated load, it can maintain
10min.
When the load greater than 150％ rated load, it can maintain 100ms.
Current-equalized
precision
≤5%
Output DC component -200mV~+200mV
Dynamic response
transient range
When the load changes in the range of 0%～100% or 100%～0%, the
output voltage≤5%
Load unbalance capacity
Can bear 100% unbalance load
Manual maintenance
bypass
It equips the maintenance bypass switch without switch time.
Ot
DC start function Equipped
