• TheDTR
®
8510mustbechargedindoors.
• Disconnectthechargeruponcompletionofthecharging
process.NiMHbatterymanufacturersdonotallowtricklecharge
foralongtimeonarecurringbasis.
Note:
• TheDTR
®
8510PowerSwitchmustbeintheOFF/CHARGE
positioninorderfortheunittocharge.
• TheDTR
®
8510cannotbeusedtotestwhileitischarging.
• Thereisnoindicationonthefrontpanelaboutthestatusof
chargingoritscompletion.TheStatusLEDisonthechargerunit
itself(seeFigure8-1).
Figure 8-1
Charge Cycle and Status LED Indication on the Charger
LED MODE
Orange Battery not connected
Orange Battery initialization & analysis
Red Fast Charge
Green with Intermittent Orange Flash Top-off charge
Green Trickle charge
Alternating Red-Green Error
