6.6. TOUCHSCREEN PANEL - SETTINGS WINDOW
From the main monitor screen (explained in section 6.1) the general settings page is accessed by pressing the "Setting" button; on
this new page the general parameters of the accessory may be set;
Alarm Key function or description of the information:
1
Enable or disable the keypad sound
2
Adjust the display brightness and the activity time before stand-by
3
Set the system's date and time
4
Select the interface language
5
Set any user password
6
Set the unit of measure for the temperature settings
7
This menu should be modified EXCLUSIVELY by a technician!
8
9
Set the name to be assigned to the indoor units
10
Set the telephone numbers of the technical assistance
11
CAUTION! Resets all settings and applies the factory settings
12
Displays the information concerning the unit
13
Press this button to exit the window and return to the main monitor
13
1
2
3
9
12
5 6
7
4
8
10
11
