12.4. MANUFACTURER (COS)
/ CONFIGURATION
(CFN) BRANCH TABLE OF
PARAMETERS
PARAMETER DEFAULT LIMITS UNIT DESCRIPTION
H01 60 H02-60 °C Max. boiler water set point value achievable with
HP
H02 30 30-H01 °C Min. boiler water set point value
H03 15 H04-30 °C Max. outside air set point
H04 0 -15 °C Min. outside air set point
H05 8 H04-H03 °C Outside air set point for heating element activation
H06 5
H06 5 0-15 °C Heating element deactivation differential
H07 65 H01-70 °C Thermal shock set point
H08 365 1-365 days Anti-bacterial treatment cycle frequency
H09 3 01-05 Num(1) Number of cycles per individual anti-bacterial
treatment
H10 15 15-30 min Duration of each cycle (time during which the
thermal shock temperature is maintained)
H11 24 6-24 hrs Interval between two consecutive cycles
H12 1 0-01 Num(1) Confi gure the polarity of digital input ID1 [1=active if
the contact is open]
H13 1 0-01 Num(1) Confi gure the polarity of digital input ID2 [1=active if
the contact is open]
H14 0 0-01 Num(1) Confi gure the polarity of digital input ID3 [1=active if
the contact is open]
H15 0 0 °C S1 probe offset (input AI1)
H16 0 0 °C S2 probe offset (input AI2)
H17 0 0-01 Num(1) Establish the mains power frequency [0=50 Hz]
H18 0 0-255 Num(3) Manufacturer password (for accessing level 2
parameters)
H19 0 0-01 Num(1) Select °C or °F [0=°C]
H20 90 0-255 sec*10 Min. time between switching off and switching on -
OFF-ON time [expressed in tens of sec.]
H21 100 0-255 sec*10 Min. time between two consecutive switch-ons -
ON-ON time [expressed in tens of sec.]
H22 30 0-255 sec. Time probe S1 remains at the boiler set point value
H23 1 0-1 Num(1) Enable Autostart function [1=active]
H24 40 35-100 % Min. speed expressed as a percentage, from 35 to
100%
H25 100 H24-100 % Max. speed expressed as a percentage, from H24
to 100%
H26 3 0 -15 °C Heat pump activation differential (Automatic
operation)
H27 60 H02-70 °C Max. boiler water set point value (Manual
operation)
H28 3 0-15 °C Heating element activation differential (Manual
operation)
H29 1 0-1 Num(1) Enable AI2 probe [1=active]
H30 0 0-1 Num(1) Enable I2 digital input [1=active]
H31 0 0-1 Num(1) Enable I3 digital input [1=active]
H32 1 0-1 Num(1) Enable anti-bacterial treatment
H33 1 0-1 Num(1) Enable dynamic set point
H34 1 0.5-2 Num Balancing line tilt
H35 20 15-25 °C Outside air temperature above the value at which
balancing began
H36 10 5-10 °C Range of the outside air on which the set point
functions
