Repair and Service
Safety Guidelines / General Repair Instruction
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
CAUTION:
Finger prints on the mirror before the Light Collector may cause reduced image
quality.
Be careful not to touch the mirror.
515131ak.cdr
Mirror before Light Collector
Figure 4
3.5.3 Safety Notes when working at the Slow Scan Drum
CAUTION:
The magnetic surface of the slow scan drum may damage sensitive parts or
attract small metallic parts.
 Keep away all parts which are sensitive for strong magnetic fields, e.g. bank cards.
 Ensure that no small metallic parts stick at the slow scan drum, e.g. screws,
metallic splinters.
CAUTION:
The Slow Scan Drum has a sensitive surface. Reduced image quality or image
plate jams possible.
Handle the Slow Scan Drum carefully.
Edition 1, Revision 2 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 3.1 / Page 10 of 11
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
