Repair and Service
Troubleshooting
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
3 No Error Code - Status LED is off or slow red blinking
Symptom
No error displayed in the Error Viewer on the workstation
Status LED is off or slow red blinking (0,6 seconds off, 0,6 seconds on)
"Digitizer start-up" message is not shown approximately 40 seconds
after switch on.
Background: The digitizer is not able to perform the hardware selftest (boards,
motors, sensors) which is executed approx. 40 seconds after switch-on.
For a default boot-up sequence refer to the digitizer service manual chapter 2,
Functional Description.
Cause 1
Power supply defective.
Solution 1
Check green LED on the external power supply or 24 V output.
If green LED is off or 24 V output not available: Exchange the power supply.
NOTE:
Depending on the power supply version, the 24 V output are available at 6 or 8 pins.
One half of the pins has positive polarity, the other half has negative polarity.
Cause 2
Power board defective.
Solution 2
Check the status of the LEDs on the PMI board indicating that power is available:
If one or more of following LEDs does not light up green, exchange the Power Board:
LD1, LD3, LD5, LD7, LD9, LD10, LD11, LD12, LD13, LD16
See chapter 3.4, Electrical and mechanical Codes, Fuses, LEDs for the location and
meaning of the LEDs.
Cause 3
PMI board defective.
Solution 3
Exchange the PMI board
Edition 1, Revision 2 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 3.3 / 6 of 46
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
