AGFA CR Series User Manual

DD+DIS155
.11E
Repair and Service
Troubleshooting
DOCUMENT CONTROL NOTE:
The controlled version of this document is available from the Agfa HealthCare Library. Any printed copy of this document is uncontrolled.
Edition 1, Revision 2 CR 10-X / CR Reader / CR 12-X / CR Advanced Reader Chapter 3.3 / 3 of 46
03-2013 Type 5151 / 100 / 110 / 200 / 210 Agfa Company Confidential
LIST OF CONTENTS
1
GENERAL SYMPTOM CLASSIFICATION...............................................................................4
2 FAULTS WITH ERROR CODES ..............................................................................................5
3 NO ERROR CODE - STATUS LED IS OFF OR SLOW RED BLINKING.................................6
4 NO ERROR CODE - STATUS LED FAST RED BLINKING .....................................................8
5 NO ERROR CODE - STATUS LED TRIPLE RED BLINKING................................................10
6 IMAGE FAULTS PARALLEL TO IMAGE PLATE RUN ..........................................................13
6.1 Calibration Lines .....................................................................................................................13
6.2 Dust Stripes.............................................................................................................................14
7 IMAGE FAULTS VERTICAL TO IMAGE PLATE RUN ...........................................................15
7.1 Banding...................................................................................................................................15
8 APPENDIX: USING THE LIMIT PATTERN TO JUDGE IMAGE FLAWS...............................16
8.1 Preparation..............................................................................................................................16
8.2 Comparing the Flatfield with the Limit Pattern........................................................................16
9 APPENDIX: ERROR CODES.................................................................................................17

AGFA CR Series Specifications

General

Type	Computed Radiography (CR) System
Resolution	Up to 10 pixels/mm (depending on model and image plate)
Connectivity	DICOM
Applications	General Radiography, Mammography
Laser Type	Solid-state laser
Power Requirements	100-240V AC, 50/60Hz
