1 General Symptom Classification
The troubleshooting procedure depends on the symptom of the fault:
Symptom Reference Section
An error is displayed in the Error Viewer 2
No error displayed:
Status LED is slow red* blinking or off
3
No error displayed:
Status LED is fast** red blinking
4
No error displayed:
Status LED is triple*** red blinking
5
Image artifacts parallel to image plate run. 6
Image artifacts vertical to image plate run. 7
* slow red blinking means: approx. 1 on/off cycle per second.
** fast red blinking means: approx. 3 on/off cycles per second
** triple red blinking means: approx. 3 on/off cycles per second followed by 1 second off
