122 1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual
7
Maintenance
Replace the Valve to Needle Tubing (Analytical and Bio-inert)
Replace the Valve to Needle Tubing (Analytical and Bio-inert)
For bio-inert modules use bio-inert parts only!
When • When contaminated, worn out or visibly damaged
• Typically once every year
Tools required p/n Description
8710-1534 Wrench, open end, 4 mm
8710-0510 Wrench open 1/4 — 5/16 inch
Parts required # p/n Description
1 G1364-68602 Tubing Kit 1 – 5 mL/min, 0.25 mm ID
Standard tubing kit for Analytical and Bio-inert Fraction Collector
1 G1364-68601 Tubing Kit 1 mL/min, 0.15 mm ID (OPTIONAL)
Preparations • Position the transport unit of the fraction collector in the Home position.
• Remove all installed trays from the tray base.
• Position the transport unit of the fraction collector in the Change Parts position and turn off the
instrument.
• It might be more convenient to remove the needle from its carrier before unscrewing the needle
tubing.
Personal injury
Risk of personal injury caused by the needle arm movement.
➔ Keep fingers away from the needle area.
To Next Page
