1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual 117
Maintenance
7
Replace the Inlet/Waste Tubings (Analytical and Bio-inert)
Replace the Inlet/Waste Tubings (Analytical and Bio-inert)
For bio-inert modules use bio-inert parts only!
When • When contaminated, worn out or visibly damaged
• Typically once every year
Parts required # p/n Description
1 G1364-68602 Tubing Kit 1 – 5 mL/min, 0.25 mm ID
Standard tubing kit for Analytical and Bio-inert Fraction Collector
1 G1364-68601 Tubing Kit 1 mL/min, 0.15 mm ID (OPTIONAL)
1 G1364-68603 Tubing Kit 4 – 8 mL/min, 0.5 mm ID (OPTIONAL)
Preparations • Position the transport unit of the fraction collector in the Home position.
• Remove all installed trays from the tray base.
• Position the transport unit of the fraction collector in the Change Parts position.
• Turn OFF the instrument.
• Remove the rear end of the fraction collector’s waste tubing from the waste container, unscrew
the front end of the fraction collector’s inlet tubing from the flow cell of the detector.
Personal injury
Risk of personal injury caused by the needle arm movement.
➔ Keep fingers away from the needle area.
