1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual 47
Using the Module
3
Configuration and Operation of the Fraction Collector
Viewing Your Results
Data Analysis
In order to display the tick marks for the collected fractions on the screen,
click Signal options from the Graphics menu. Then choose Separated in the Layout
dropdown list.
To review your chromatograms, file information and a fraction list, select the
Data Analysis view and click Fraction Task as displayed below.
Figure 8 Fraction Task button
In order to display the tick marks for the collected fractions on the screen,
click Signal options from the Graphics menu. Then choose Separated in the
Layout dropdown list.
3XULILFDWLRQ7DVN
&KURPDWRJUDPZLWK)UDFWLRQ7LFN0DUNV
)UDFWLRQWDEOH
