134 1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual
7 Maintenance
Exchange the Diverter Valve
7
Install the valve to needle tubing at the new diverter
valve.
8 A color coded ring on one of the tubings and the valve
body indicates, which tubing belongs to which port.
9 Connect the finger-tight fittings of the inner tubing kit to
the ports of the diverter valve. The tubings must run into
the ports of the diverter valve in horizontal, parallel lines.
NOTE
The tubings must not be bent or twisted.
Next Steps:
10 Re-install the tray(s) in the tray base.
11 Start the instrument.
12 Close the front cover.
