1260 Infinity II Analytical-Scale & Bio-inert Fraction Collector User Manual 185
Hardware Information
10
Interfaces
• CAN connectors as interface to other modules
• LAN connector as interface to the control software
• RS-232C as interface to a computer
• USB (Universal Series Bus) as interface to a computer
• REMOTE connector as interface to other Agilent products
• Analog output connector(s) for signal output
Fraction Collectors
G7159B 2 Yes Yes No No E
G7166A 2 No No No No No Requires a host
module with on-board
LAN with minimum
FW B.06.40 or C.06.40,
or with additional
G1369C LAN Card
G1364E/F, G5664B 2 Yes Yes No No E THERMOSTAT for
G1330B
Others
G7116A/B 2 No No No No No Requires a HOST
module via CAN
G7122A No No No Yes No A
G7170B 2 No No No No No Requires a host
module with on-board
LAN with minimum
FW B.06.40 or C.06.40,
or with additional
G1369C LAN Card
Table 1 7 Agilent InfinityLab LC Series Interfaces
Module CAN USB LAN
(on-board)
RS-232 Analo
g
APG
(A) /
ERI (E)
Special
The detector (DAD/MWD/FLD/VWD/RID) is the preferred access point for control via
LAN. The inter-module communication is done via CAN.
