Agilent 4155B/4156B User’s Guide Vol.2, Edition 5 3-59
Measurement Functions
Compliance
Table 3-7 V Compliance Resolution
Table 3-8 I Compliance Setting Range
HPSMU 1 nA to 10 mA 0 to 200 V
100 mA (0 £ | I | £ 50 mA) 0 to 200 V
100 mA (50 mA < | I | £ 115 mA) 0 to 100 V
1 A (0 £ | I | £ 50 mA) 0 to 200 V
1 A (50 mA < | I | £ 125 mA) 0 to 100 V
1 A (125 mA < | I | £ 500 mA) 0 to 40 V
1 A (500 mA < | I | £ 1 A) 0 to 20 V
Unit V Compliance Resolution
HRSMU 0 V £ | V | £ 2 V 100 mV
MPSMU 2 V < | V | £ 20 V 1 mV
HPSMU 20 V < | V | £ 40 V 2 mV
40 V < | V | £ 100 V 5 mV
100 V < | V | £ 200 V 10 mV
Unit Output Range I Compliance Setting Range
HRSMU 2 V 100 fA to 100 mA
20 V 100 fA to 100 mA
40 V 100 fA to 50 mA
100 V 100 fA to 20 mA
MPSMU 2 V 1 pA to 100 mA
20 V 1 pA to 100 mA
40 V 1 pA to 50 mA
100 V 1 pA to 20 mA
Unit Output Range
V Compliance
Setting Range
