Agilent Technologies 4263B - Page 10

○
C
Copyright 2007 Agilent Technologies
Change the Measurement Uncertainty value of 0 m Impedance Measurement Accuracy Test
for 0 m Capacitance Measurement Accuracy Test (Meas. Time Mode: LONG) (Page 9-41) to
the following information.
Standard
Test Signal
Frequency
Parameter
Measured Test Limits
Test Result
1
Measurement
Uncertainty
1 μF 100 Hz Cp ±0.0018 μF pF ± 0.000074 μF
D ±0.0018 ± 0.000047
1 μF 120 Hz Cp ±0.0018 μF pF ± 0.000073 μF
D ±0.0018 ± 0.000047
1 μF 1 kHz Cp ±0.0011 μF pF ± 0.000067 μF
D ±0.0011 ± 0.000032
1 μF 10 kHz Cp ±0.0026 μF pF ± 0.00014 μF
D ±0.0026 ± 0.000069
1 μF 100 kHz Cp ±0.0176 μF pF ± 0.00018 μF
D ±0.0176 ± 0.00032
Change 5
Change the Measurement Uncertainty value of 0 m Impedance Measurement Accuracy Test
for 0 m Capacitance Measurement Accuracy Test (Meas. Time Mode: MED) (Page 9-41) to
the following information.
Standard
Test Signal
Frequency
Parameter
Measured Test Limits
Test Result
1
Measurement
Uncertainty
0.01 μF 100 Hz Cp ± 0.063 nF pF ± 0.00070 nF
100 Hz D ±0.0063 ± 0.000043
0.01 μF 100 kHz Cp ± 0.271 nF pF ± 0.0023 nF
100 kHz D ±0.0271 ± 0.00044
Change 6
Change the Measurement Uncertainty value of 0 m Impedance Measurement Accuracy Test
for 0 m Capacitance Measurement Accuracy Test (Meas. Time Mode: SHORT) (Page 9-41) to
the following information.
Standard
Test Signal
Frequency
Parameter
Measured Test Limits
Test Result
1
Measurement
Uncertainty
0.01 μF 100 Hz Cp ± 0.179 nF pF ± 0.011 nF
D ±0.0179 ± 0.00072
0.01 μF 100 kHz Cp ± 0.287 nF pF ± 0.00081 nF
D ±0.0287 ± 0.00069
