Change 3
Change the Measurement Uncertainty value of DC Bias Level Accuracy Test (Page 9-39) to
the following information.
DC Bias Level
Test Limits
Test Result
1
Measurement
Uncertainty
0 V ±0.002 V V ± 0.088 mV
1.5 V ±0.077 V V ± 0.44 mV
2 V ±0.102 V V ± 0.92 mV
Change 4
Change the Measurement Uncertainty value of 0 m Impedance Measurement Accuracy Test
for 0 m Capacitance Measurement Accuracy Test (Meas. Time Mode: LONG) (Page 9-40) to
the following information.
Standard
Test Signal
Frequency
Parameter
Measured Test Limits
Test Result
1
Measurement
Uncertainty
10 pF 100 kHz Cp ±0.331 pF pF ± 0.0040 pF
D ±0.0331 ± 0.00043
100 pF 1 kHz Cp ±0.19 pF pF ± 0.0074 pF
D ±0.0019 ± 0.000063
100 pF 10 kHz Cp ±0.44 pF pF ± 0.017 pF
D ±0.0044 ± 0.00023
100 pF 20 kHz
2
Cp ±1.10 pF pF ± 0.021 pF
D ±0.0110 ± 0.000091
100 pF 100 kHz Cp ±1.37 pF pF ± 0.019 pF
D ±0.0137 ± 0.00033
1000 pF 100 Hz Cp ±2 pF pF ± 0.000098 nF
D ±0.0020 ± 0.000063
1000 pF 1 kHz Cp ±0.0012 nF pF ± 0.000092 nF
D ±0.0012 ± 0.000064
1000 pF 100 kHz Cp ±0.0128 nF pF ± 0.00012 nF
D ±0.0128 ± 0.00033
0.01 μF 100 Hz Cp ± 0.018 nF pF ± 0.00065 nF
D ±0.0018 ± 0.000022
0.01 μF 120 Hz Cp ± 0.018 nF pF ± 0.00059 nF
D ±0.0018 ± 0.000022
0.01 μF 1 kHz Cp ± 0.011 nF pF ± 0.00076 nF
D ±0.0011 ± 0.000021
0.01 μF 10 kHz Cp ± 0.018 nF pF ± 0.00067 nF
D ±0.0018 ± 0.000036
0.01 μF 100 kHz Cp ± 0.128 nF pF ± 0.00087 nF
D ±0.0128 ± 0.00022
0.1 μF 1 kHz Cp ± 0.11 nF pF ± 0.0068 nF
D ±0.0011 ± 0.000023
0.1 μF 100 kHz Cp ± 1.47 nF pF ± 0.015 nF
D ±0.0147 ± 0.00026
